The Gedore No. 7 Combination Spanner combines a precision-ground open end and offset ring end for reliable tightening and loosening of nuts and bolts.
- Has the same size at both ends.
- The jaw is precision-ground to the exact nominal size for optimum contact with nuts and bolts.
- Slim jaw and jaw walls make this spanner lighter overall.
- The ring end is angled at 15° with a UD profile
- The mouth position is 15° and is precisely ground to exact nominal dimension for optimum contact surfaces
- Manufactured from GEDORE vanadium steel 31CrV3, with chrome-plated finish.
- Available individually or in selected combination spanner sets:
-
Spanner set 7-17M: includes 17 spanners (sizes 6mm - 22mm)
-
Spanner set 7-26M: includes 26 spanners (sizes 6mm - 32mm)
Specifications:
| No. |
Size (mm) |
Length (mm) |
No. |
Size (mm) |
Length (mm) |
No. |
Size (mm) |
Length (mm) |
| 7-6 |
6 |
100 |
7-15 |
15 |
190 |
7-24 |
24 |
282 |
| 7-7 |
7 |
110 |
7-16 |
16 |
200 |
7-25 |
25 |
290 |
| 7-8 |
8 |
120 |
7-17 |
17 |
210 |
7-26 |
26 |
302 |
| 7-9 |
9 |
130 |
7-18 |
18 |
220 |
7-27 |
27 |
310 |
| 7-10 |
10 |
140 |
7-19 |
19 |
230 |
7-28 |
28 |
320 |
| 7-11 |
11 |
150 |
7-20 |
20 |
240 |
7-29 |
29 |
330 |
| 7-12 |
12 |
160 |
7-21 |
21 |
252 |
7-30 |
30 |
340 |
| 7-13 |
13 |
170 |
7-22 |
22 |
262 |
7-32 |
32 |
380 |
| 7-14 |
14 |
180 |
7-23 |
23 |
270 |
|
|
|
